LIGHTDROP SPLICE 08
LIGHTDROP SPLICE 08
LIGHTDROP SPLICE 08
Featuring:
- 8 Hardened Quarter Turn (FastConnect compatible) bottom ports for branch connections.
- 48 fibres splicing capacity.
- 1 oval optical cable entry up to 18mm.
- 2 branch optical cable entries and up to 14mm.
- Integration of optical splitters (i.e. 4 splitters 1:2 or 2:2).
- Othre splice trays and optical splitter configurations available.
- Mounting bracket options for overlenght cable storage.
- Aginode ref: LDSFSP08HQNANA04SD00NASTNANANA
Description
Description
Standards
Aginode specification
Terminal max. attenuation*:
| Splitter ratio | Output |
| 1:8 | 4.20 dB |
| 2:8 | 4.50 dB |
*Total terminal attenuation, including insertion losses from pre-connectorization.
