LIGHTDROP XS - TAP

Featuring:

1 Hardened Quarter Turn (FastConnect compatible) top TAP IN port.
2 Hardened Quarter Turn (FastConnect compatible) bottom ports for SPLITTER OUT and TAP OUT.
Mounting bracket options.

Description

Aginode specification

TAP ratio	TAP OUT	Splitter port
70% - 30%	2.10 dB	6.10 dB

*Total terminal attenuation, including insertion losses from pre-connectorization.

结构特性

颜色

黑

材料

PP

机械特性

IK Rating

8

使用特性

安装类型

户外

操作温度，范围

-40...65 °C

包装

箱

RoHS compliant

Yes

抗UV

是

防水

IP 68
